Samson Amsteel Blue -12 Strand Dyneema Rope

*Please note – 7/64″ Amsteel Blue is an 8 strand construction.

AmSteel^®-Blue is a torque-free 12-strand braid that, size-for-size, is as strong as steel but outlasts wire 3:1, making it an excellent wire rope replacement. At only 1/7th the weight of wire, it is a safe and efficient solution for all marine applications where wire is traditionally used. The combination of Dyneema^® fiber and Samthane coating provide abrasion and tension fatigue resistance for superior wear. AmSteel^®-Blue is easily spliced and inspected. AmSteel^®-Blue is recommended for split-drum winch applications. It is not recommended for use on H-bitts, capstans, or cleats if surging or rendering the rope is required. AmSteel^®-Blue has been verified by ABS according to MEG4, and is type approved by: ABS, BV, DNV, Lloyd’s, and RMRS.

DIAMETER	TENSILE STRENGTH (LBS)
7/64″	1,600
1/8″	2,500
3/16″	5,400
1/4″	8,600
5/16″	13,700
3/8″	19,600
7/16″	23,900
1/2″	34,000



Amsteel Blue features:

• Abrasion resistant
• Easy to splice
• Excellent wear characteristics
• Extremely low stretch
• Flexible
• Floats
• High strength
• Highly flex-fatigue resistant
• Lightweight
• Maximum strength-to-weight ratio
• Samthane coated
• Similar elastic elongation to wire rope
• Torque-free construction
• Wire rope replacement

 Use Amsteel Blue for:

• ATV / Jeep Winch Lines
• Working Winch Lines
• Control Lines and Halyards
• Davits
• Emergency Tow Systems
• General Working Lines / Vessel Mooring
• Lifelines / lifting slings
• Primary Mooring Lines / Non-jacketed
• Pulling / Stringing Lines
• Reef Lines
• Running Back
• Shield Hauler
• Stage, Event, and Special Effects Rigging
• Trapeze Line
• Trawl or Bridle Lines
• Tug Lines
• Robotics projects
